GJD226.1U Siemens Actuator

Datasheet Fire and Smoke Damper Actuator 20 lb-in 2-position control , Spring Return, 120VAC compatible with built in Electronic Fuse Link capability with two fixed built-in auxiliary switches. For use with combination fire and smoke dampers. Designed to meet UL555S. Technical Specifications Actuator Type                     Electronic Fire and Smoke Actuation Style Rotary Control or Fire/Smoke Type Fire/Smoke Control Damper Electronic Fusible Link (EFL) YES Plenum or Standard Rating Standard Torque 20 lb-in Fail Safe Yes Spring return function Spring return function Control Signal 2-position Positioning time Operating: 30 s, Closing (power loss) with spring return: Typical 15 s Position feedback No Power consumption Running: 10 VA / 5 W, Holding: 5 VA / 3 W Ambient temperature, operation -18…55 °C; 0…130 ºF Angular rotation 95° Operating voltage 120 VAC Supply Voltage 120 VAC Frequency 50/60 Hz Auxiliary Switch Yes Auxiliary switch 2 Cable length 3 ft Dimensions (W x H x D) 2.83 x 5.61 x 2.48 in Material, housing NEMA 1, plenum-rated plastic Standard UL60730; cUL CSA 60730; CE conformity for Residential, Commercial, and Industrial environments
